This product is an outdoor distribution device rated at 24kV, three-phase AC 50Hz, mainly used to switch and close/open the load current, overload current, and short-circuit current within power systems, suitable for protection and control purposes in substations and industrial/mining distribution systems, and for frequently operated locations on rural grids.
Features:
The product is compact and lightweight, resistant to condensation, and maintenance-free, able to adapt to relatively harsh climatic conditions and polluted environments, providing stable and reliable long-term outdoor operation and greatly reducing maintenance workload and cost.
Applications:
Widely used on overhead lines and distribution zones of urban and rural grids, undertaking load control, overload protection, and short-circuit fault clearance, particularly suitable for outdoor distribution applications with relatively harsh climate conditions requiring frequent operation.
| Item | Unit | Parameter |
| Rated Voltage | kV | 24 |
| Rated Frequency | Hz | 50 |
| Rated Current | A | 630 |
| Rated Short-Circuit Breaking Current | kA | 20 |
| Rated Peak Withstand Current (Peak) | kA | 50 |
| Rated Short-Time Withstand Current | kA | 20 |
| Rated Short-Circuit Making Current (Peak) | kA | 50 |
| Mechanical Life | Times | 10000 |
| Rated Number of Short-Circuit Breaking Operations | Times | ≥ 30 |
| Power Frequency Withstand Voltage (1min): (Wet) (Dry) Phase to phase, phase to earth / Break | kV | 65/79 |
| Lightning Impulse Withstand Voltage (Peak) Phase to phase, phase to earth / Break | kV | 125/145 |
| Auxiliary Circuit 1min Power Frequency Withstand Voltage | kV | 2 |
